Specifications
Supplier part number: CLCD_63
Name:Rexroth - Bosch Fork Type Mounting Block (Type CLCD - Size 63) - For Cylinder Range CDH2 , Piston Diameter D=100 mm
Description:For the Rexroth CDH2 cylinder with a 100 mm piston diameter, the correct fork-type mounting block is the CLCD 63. The "63" in the designation refers to the required mounting pin diameter of 63 mm . Parameter Specification Type CLCD 63 Material Number R900542886 Nominal Force 200 kN Pin Diameter (ØCK H9) 63 mm Weight (approx.) 17.0 kg 📏 Dimensional Data (in mm) Dim. Value Dim. Value Dim. Value CL h16 140 CM A12 63 FL js12 112 ØHB H13 33 KL 20 LE min. 75 MR max. 63 RC js14 100 ØS 48 SL 164 TB js14 210 UR max. 160 UH max. 270 Note: This clevis bracket meets the requirements of ISO 8132 . The associated mounting pin (63 mm diameter, tolerance m6) and its locking feature are included in the scope of supply but are not pre-assembled at the factory .
